设备配置选型 Device configuration
快速油缸：速度和压力集合气动和普通油缸的优点，速度快压力足，压力可调，常用出力20-60T可选。一次行程可设定快速转换慢速即两段速。推荐中大型家电面板控制板产品使用。
普通油缸：压力和速度满足IMD/IML工艺拉伸高之技术需求。压力可调。常用出力5-20T可选。适用产品侧边包边拉伸产品及中小型家电面控制板产品。
高级配置：触屏操作配合PLC控制系统，电机驱动加热板。成型保压时间、加热时间、加热温度数字化触屏调整并可以编号记录，作为技术参数长期保存，输入编号即可调出生产参数，便于生产管理。
标准配置：按钮操作，功能直观。和同等规格设备相比性价比高。
fast oil cylinder: set speed and pressure pneumatic and ordinary oil cylinder, the advantages of fast foot pressure, pressure adjustable, common output 20-60 t is optional. A schedule can be set fast conversion speed slow or two paragraphs. Recommended use large home appliance panel control board products.
The common oil cylinder, pressure and velocity to meet on IML/IML craft stretching high technical requirements. Pressure is adjustable. Commonly used output 5-20 t is optional. Applicable product side bag edge is tensile products and small and medium-sized electrical appliances control panel products.
Advanced configuration: touch screen with PLC control system, motor drive the heating plate. Shaping the holding time, heating time, heating time, heating temperature digital touch screen can adjust and serial number record, long-term preservation as a technology parameters, input a number callout production parameters, convenient for production management.
Standard configuration: button operation, intuitive functionality. Compared with the same specification equipment cost-effective.
